Late 2006 Macmini1,1 won't display anything before getting out of sleep

Question

Level 1

4 points

Late 2006 Macmini1,1 won't display anything before getting out of sleep

Hello,

This A1176 Mac Mini is running Boot Camp with Windows Xp on one side and Mac Os X Snow Leopard on the other.

I can hear the chime at startup. Hooked up to a VGA monitor, the screen stays black for a while. Then I can only see a flashing horizontal line every 3 or 4 seconds, on different positions each time. If I press the Power button, the Mini goes to sleep. After hitting a keyboard key, the Mini wakes up and I can see my Snow Leopard desktop.

I've tried several startup key combinations, using two different USB keyboards, hooked on the first USB port next to the monitor port, but if they ever did something, I can't tell because of the black screen.

If I boot on Windows Xp, nothing shows up either until the Xp logo and loading bar screen, then it's all good.

I hadn't used this machine in several years. I kinda remember issues with the CD drive, which I would mind disconnecting from the motherboard.

Also, at startup, I sometimes hear loud clear noises, which, as a French native speaker, I would describe as a "tak.... tak... tak... " sound, repeated a few times only before they stop.

Please tell me if I can give any more information to help you help me solve this!

Thanks a lot. :)

Posted on Apr 7, 2020 12:24 PM

Reply

Answer 1

Top-ranking reply

QuickPost

Level 10

103,371 points

Apr 7, 2020 3:56 PM in response to aGuillaume

Hello,

Try running the following tests:

How to reset the System Management Controller (SMC) on your Mac - Apple Support

Reset NVRAM or PRAM on your Mac - Apple Support

How to use Apple Hardware Test on your Mac - Apple Support

Reply

Answer 2

aGuillaume Author

Level 1

4 points

Apr 8, 2020 9:08 AM in response to QuickPost

Thank you for these suggestions.

Additional information: it takes about 45 seconds before I see the screen flicker. The time it might take the Mac to boot and get to the desktop?

But the monitor detects input as soon as I boot the Mac up. Its power led goes from sleep color (orange) to active color (blue).

About SMC, I followed the instructions for Desktop computers:

1. Shut down your Mac, then unplug the power cord.

2. Wait 15 seconds, then plug the power cord back in.

3. Wait 5 seconds, then press the power button to turn on your Mac.

But the Mac had been turned off and unplugged for several years, so I guess the SMC was well reset? :)

About NVRAM:

If I press Alt+Ctrl+P+R (don't have any Apple Keyboard at my disposal) before the first chime, I will hear the chime maybe ten seconds later. But I'll never hear a second chime, and then I see the flicker.

If I press Alt+Ctrl+P+R after the first chime, I won't hear it a second time. And then I'll see the flicker.
