With a slightly higher CPU load (during the game), there are repeated restarts, pink stripes appear on the black screen. I cannot interpret the reports (they are identical, see example below). The problem does not occur with the same load on Macbook Air 2015 (Football Manager 2020 game running via Epic Launcher and Chrome). Big Sur 11.1.
MacBook Air 13″, macOS 11.1
Is there any update on this? Many users seem to have the same issue.
I have contacted apple support and not had any useful resolutions. MacBook M1 pro.
panic(cpu 0 caller 0xfffffe0019f904c4): "dart-disp0 (0xfffffe2336540000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x38000 (TTBR 0 SEG 0 PTE 0xe) ERROR_STATUS 0x80000004 TIME 0x2ae3db41d3de TTE 0 AXI_ID 0)"
Debugger message: panic
Memory ID: 0x6
OS release type: User
OS version: 20C69
Kernel version: Darwin Kernel Version 20.2.0: Wed Dec 2 20:40:21 PST 2020; root:xnu-7195.60.75~1/RELEASE_ARM64_T8101
Fileset Kernelcache UUID: 3E6AA74DF723BCB886499A5AAB34FA34
Kernel UUID: 48F71DB3-6C91-3E62-9576-3A1DCEF2B536
iBoot version: iBoot-6723.61.3
secure boot?: YES
Paniclog version: 13
KernelCache slide: 0x0000000010de0000
KernelCache base: 0xfffffe0017de4000
Kernel slide: 0x0000000011920000
Kernel text base: 0xfffffe0018924000
Kernel text exec base: 0xfffffe00189ec000
mach_absolute_time: 0x10784410043..............................
panic(cpu 1 caller 0xfffffe0018f044c4): "dart-disp0 (0xfffffe2336758000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x2468000 (TTBR 0 SEG 0x1 PTE 0x11a) ERROR_STATUS 0x80000004 TIME 0x4431d7862b51 TTE 0 AXI_ID 0)"
Debugger message: panic
Guys, maybe the information will be useful for someone. So.. I was hoping that the problem with kernel panic arises purely from connecting the external monitor to hdmi, so I bought a Display Port to usb-C cable and connected my monitor directly to the computer port. And got panic again ...
Thus, the problem is not only in connection via hdmi, but when connecting an external monitor in any way ...
I may be the only person that had Kernel Panic with Intel Mac. I bought 2.0GHz Intel Core i5 Quad-Core Processor with Intel Iris Plus Graphics, 1TB storage at the end of April from Apple Store. Then I used the Intel Macbook Pro and connected with BenQ monitor using Mophie USB-C to Mini DVA that I bought from Apple Shop. After that, I kept having Kernel Panic almost every week and sometimes, it happened without connecting to anything! After frustration, I went to Apple Store and got it replaced with M1 Macbook but it still keep having the same Kernel Panic. So I do not think the issue is related to M1 Chip only.
This issue doesn't only happen on M1. My Macbook Pro was intel Mac which I bought in April 2021 and I had the same problem many many times until they replaced me with M1 mackbook Pro but the problem still hasn't resolved. :(
I did a similar test with a switch to the display port to usb C and panic appeared the same way, 2 times a day.
Now I'm free from panics for the 3rd day, having switched to version 1.15.2 of mac os.
What version do you have installed?
Adding my MBP to the list. Random crashes whether using an external display or not, with probably quite high RAM usage (used for design work).
But sometimes it crashes just with safari open and nothing else. It can be entering info in a form or switching tabs and then it just freezes > purple screen > restart.
It’s now happening about twice a day making working on it very frustrating.
My recommendation - ignore some of the chatter here around changing hardware - start with a simple software update to the latest official Mac OS release (11.15.2 at this time). And try again.
This from someone with 2 Mac mini M1s, and 2 MacBook Air M1s. All of which failed under 11.15.1, none have failed in the week since updating to 11.15.2.
Same problem, I just don't have any external monitors. It has happened twice now, I've had the machine maybe a month.
MacBook Air M1 8gb of RAM
Same code as everyone else when I try to investigate the cause
I have the same issue too. I was googling on safari only. No game or any. The screen shut down with pink stripes immediately. MacBook Air M1.
panic(cpu 0 caller 0xfffffe0022085798): "dart-disp0 (0xfffffe2332ee4000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x32dc000 (TTBR 0 SEG 0x1 PTE 0x4b7) ERROR_STATUS 0x80000004 TIME 0x12fb88f6751f2 TTE 0 AXI_ID 0)"
Debugger message: panic
Original thread:
panic(cpu 0 caller 0xfffffe0030c844c4): "dart-disp0 (0xfffffe23365ec000): SMMU(SMMU) error: SID 0 PTE invalid exception on read with DVA 0x3304000 (TTBR 0 SEG 0x1 PTE 0x4c1) ERROR_STATUS 0x80000004 TIME 0x2e4ed72a3570 TTE 0 AXI_ID 0)"
Your latest post:
panic(cpu 0 caller 0xfffffe0017f15798): "dart-usb1 (0xfffffe2333430000): DART(DARTLLT) error: SID 1 PTE invalid exception on write with DVA 0x642c0 (TTBR 0 SEG 0 PTE 0x19) ERROR_STATUS 0x81000404 TIME 0x3e8658ca4a TTE 0 AXI_ID 0x1)"
With respect, this isn't the same panic kernel as this thread was originally covering. I believe from the information presented in the recent posts that 11.15.2 fixes the dart-disp0 display-related panics. Your post is different, related to the USB subsystem.
Might try a USB C TO DISPLAYPORT CABLE...
6 Best USB-C to DisplayPort Cables That You Can Buy (guidingtech.com)
I have had the same problem - Mac Pro M1.
Suddenly the Mac restarts.
Honestly, a very disappointing problem, since it can restarts without saving the things I'm working on.
Next time this happens I'll post the logs here.
Hello guys,
I had the same issue on my Air M1 and since it was still in its 1year warranty I sent it to an Apple service. Apparently they replaced the entire motherboard so this is an hardware issue. This solved the problem and haven't got that error anymore. You should get yours checked as long as is still in its warranty.
Update :
I took mine into the apple store to be looked at. There was a hardware fault. Apple have replaced my Mac.
I would recommend taking it into store.
hey
I've attached log file
Just FYI
I use usbc hub and external display.
Kernel panic happens twice per weak at least
Macbook Air M1 - kernel panic
