Can I image my hard drive

I just bought a new SSD drive and was wondering if it was possible to image my current hard drive and save it to an external and boot from that image on the new hard drive or any other ways from not having to start from scratch

Posted on Feb 21, 2012 12:08 PM

Reply
18 replies

Feb 21, 2012 12:11 PM in response to airtas

Yes by doing the following:


Clone using Restore Option of Disk Utility


  1. Open Disk Utility from the Utilities folder.
  2. Select the destination volume from the left side list.
  3. Click on the Restore tab in the DU main window.
  4. Check the box labeled Erase destination.
  5. Select the destination volume from the left side list and drag it to the Destination entry field.
  6. Select the source volume from the left side list and drag it to the Source entry field.
  7. Double-check you got it right, then click on the Restore button.


Destination means the external backup drive. Source means the internal startup drive.

Feb 21, 2012 1:16 PM in response to airtas

Once you made the clone, reboot holding the option key down, the external clone will be a bootable option, whcih you then can run CCC and clone onto the SSD drive or get online for assistance like normal.


Of course you need to format the internal drive in Disk Utility first before cloning onto the SSD.


Options: GUID, Format OSX Extended(J) under the parititon tab.



You need a powered external drive for the clone, no Filevault on OS X.

Feb 21, 2012 1:14 PM in response to airtas

John Tasinas wrote:


it doesn't let me drag the mac drive to the destination..........


Shouldn't it be the other way around?



Just use the free Carbon Copy Cloner for OS X, it's very easy, the default setting is perfect, just select a too and from and click clone. 🙂


http://www.bombich.com/index.html



For Windows bootcamp you'll need the free Winclone.


http://download.cnet.com/Winclone/3000-2242_4-172338.html



Windows Bootcamp adds a wrinkle, because once you've got OS X cloned and setup you need to restore Bootcamp/Windows and that's where Winclone comes in.



good Luck. 🙂

Feb 21, 2012 1:39 PM in response to airtas

If you intend on cloning your current drive to the SSD and then using the SSD as the internal drive do this:


Use CCC or SuperDuper to clone your internal drive to the externally connected SSD (use the defaults in either of the 2 programs suggested) your internal drive will be the source and the external SSD will be the destination, it looks like this in CCC (see below), SuperDuper is very similar.

User uploaded file

The default settings will get you what you want. Make sure the SSD is partitioned and formatted correctly for use with OSX (DS Stores instructions are correct.)


When the clone is complete reboot to the external and verify that it works, then swap the internal and external drives.

Feb 21, 2012 2:08 PM in response to airtas

John Tasinas wrote:


same result either way, is it because the drive is NTFS?



You obviously have a lot to learn before attempting anything, I suggest you read through my extensive thread here, perhaps consider having a local Mac/PC geek do the SSD upgrade for you.


https://discussions.apple.com/thread/3358920



Try cloning to a external drive a few times until you get the hang of things before attempting the SSD upgrade.


There are videos here how to perform the manual hardware upgrade


http://eshop.macsales.com/installvideos/




Perhaps you should explain your hardware specs and why you feel a upgrade to a SSD is going to help you.


If you don't know, older Mac's use a slower SATA 3 connection, unlike newer Mac's with SATA 6, even if you upgrade to SSD your hardware may still slow you down. Also the limited storage of some SSD's may be a hinderance to Bootcamp, you'll have to buy a very expensive 500GB to hold both OS X and Bootcamp.


Sometimes it's better to get a larger 750GB -1TB 7,200 RPM hard drive for older hardware, it's a better match, you get the fast speed and large storage. 🙂


SSD in your case may be a waste of money. Or perhaps you have a software issue in OS X that a reinstall will cure better.


So please explain your reasons and state your hardware specs, operating system and installed software so we may assist with perhaps a more tailored solution to your real problem. 🙂

Feb 21, 2012 3:51 PM in response to ds store

Hi ds store,


I recently found a good deal on a 128 gb SSD for my 2009 version Macbook Pro


I have reformatted and replaced hard drives numerous times in windows but have never done it on a mac.


Was wondering if there was a better way than moving all my files to an external drive, installing the new hd and running the OSX restore discs and then brining the files back


Then having to download all my applications again


I had never tried imaging a current system and was curious on how easy it was or if there were any negative impacts



Thanks for your write up
