Samsung 850 EVO in Early Macbook Pro

Hi,


I had replaced my old hardrive in my Macbook Pro Early 2011 with a samsung 840 EVO, everything worked beautifully until it didnt. In the end i couldent even repair or remformat my drive. So i returned it and got a Samsung 850 EVO instead. In the mean time i put my old HDD back in and everything worked as it should.



Yeasterday i put the replacement SSD Straigt out of the box into the Mac.,I have been trying for 24 hours now, and im not even able to Format the drive using diskutil not from Recovery Mode or from my OSX Install drive. the Drive shows up in Diskutility and is verified as okay. I finanlly got it formated using the terminal, then the OSX installation failed, tried to repair the disk with diskutillity in recovery Mode, and got a message that the GUID Partitiontable was not working, repaired disk and got the message the disk could not be mounted.



Is this simply a hardware error with my mac? could it be I need to replace the SATA Cable?

OS X Yosemite (10.10.1)

Posted on Jan 17, 2015 12:36 AM

Reply
74 replies

Apr 2, 2015 10:51 PM in response to dwb

I'm having a very similar problem with a samsung 850 evo ssd inside a mid 2012 MacBook Pro running Yosemite public beta. (I understand it could be a beta problem haven't rolled back yet)

i was getting the odd crash and then dreaded white screen telling me I shutdown because of a problem. first time it happened I searched forums and reseated ram. This seemed to work for a short while then back again. It got more and more frequent until yesterday it crashed and then wouldn't boot up.

Went into to recovery mode to verify disk where it came up with an issue on the samsung. (I have two hard drives installed) so repaired disk and tried to do a time machine backup. This is when it started rebooting into recovery mode again after about an hour or so (different time every time). I tried removing the original hard drive (which was in the primary slot and moving the ssd from the dvd drive mod into the primary). Still the same problem. I haven't tried any of the suggestions here yet. But I'll let you know how I get on.

May 12, 2015 10:20 AM in response to Muldvarp007

Hello, I just bought the same SSD and tried to format it using the internal cable, but it failed. I'm curious to see if you've solved your problem?


I read the reply where it says that it can't be done internally, so I'm going to get a SATA-USB cable tonight to try the external format.

If that doesn't work, I guess I'll have to replace the ribbon cable since I've had a similar problem with another brand new SSD which I ended up returning to the shop.

Jun 29, 2015 4:57 AM in response to Muldvarp007

Somehow I had the same problem but was able to fix it. My computer is a 2010 macbook pro running on Mavericks


After cloning my SSD, I installed my 250 gb 850 evo SSD into my macbook pro but it wasn't detecting. Thought the cable was damaged during installation so I reinstalled my old HDD and it worked. I installed my SSD into an external casing and was able to boot up the SSD externally. So I figured that my SSD must be working. I was considering buying a new SATA cable because the impression I got from reading all the forums was that my internal SATA cable was damaged.


I reinstalled the SSD, but this time I held 'option' and it detected my SSD as an internal drive!


My computer was exponentially faster on the internal SSD. For a couple of days, I was turning on my computer by pressing option. Eventually, I mucked around with my settings, went to system preferences, startup disk, clicked on my SSD, and now my computer turns on without holding option.


Hope this helps someone!

Jul 2, 2015 4:51 PM in response to Muldvarp007

I just put in the ssd 850 evo 500gb to my early 2011 macbook pro. I was able to install it, then from disk utility, format and start restore from time machine (my old HDD died). Everything worked well so I decided to upgrade to Yosemite. That is when things went bad. Started to freeze occasionally at first that I could get out of by closing the program ,then progressively got worse until it froze where I couldn't get it going (all within a few hours). Had grey screen that wouldn't respond until I forced quit. I'm thinking the problem is with Trim. Because you can't have Trim and security both with Yosemite, I went back and was able with several tries to reformat the drive and reinstalled Mavericks then enabled Trim. It has worked fast and without problems so far. I thought the samsung 850 evo ssd had internal garbage collection with it, but must not work well in Yosemite.

Oct 12, 2015 9:41 PM in response to Muldvarp007

So I came here looking for answers as my Macbook Pro 13 (2012) was having problems with exactly the same drive. I'm covered by Apple Care so I sent the computer in for repair. The Genius changed the sata cable and tried with a new drive and that worked perfectly. However, with my 850 EVO it was reporting issues with SMART and would not boot/format/reinstall properly.


I then went to look for SMART utilities to tell me the cause of the error and it appears that there are a huge number of CRC errors, a symptom that seems to point to either a busted cable, bad TRIM, bad SATA controller or a broken drive. The same SSD works perfectly on a Windows notebook so I was beginning to feel that it wasn't a problem with the drive itself.


My final conclusion was that with the old TRIM tool on OSx, it was incompatible with El Capitan and logged a lot of CRC errors on the SSD. This it turn triggered a SMART error which made OSx halt operations on the SSD. Windows seem to be a little more laxed on the SMART check and would continue to run fine on the same SSD that won't run on a Macbook. I'm going to exchange the SSD and see if a new one fixes this.

Dec 3, 2015 6:53 PM in response to olePigeon

The same problem here. Mid 2012 Macbook pro recognizes Samsung EVO 850 but I can't format it (or erase it) - it gives me error:

"Unable to write to the last block of the device"


There is no firmware update for this SSD, the only thing I can try is to replace sata cable.

(My old hdd (original) died. So this might be solution)

Anyone else solved a problem with sata cable?
