Lost bootcamp after using mini tool partition to increase windows partition size

Seems to be a very common problem that requires a lot of customisation so many thanks for the support in here people 🙂

There are so many threads to go through but figured to mention my problem maybe it has been solved before and i can follow the footsteps.

What i did was reduce OS X partition size, restart in bootcamp windows 7 and used Mini Tool Partition to acquire the free space. Restarted windows worked great for a couple of days until i restarted in OS X which as most threads here have boot camp is called disk04 and can not be mounted nor can it been seen in startup disk.


All i want is to get the windows working as i have no backup (i know!) and to sort out the missing space.

I will continue to go through the post but any pointers will be appreciated !


As per original post, here is the results:

Vmini:~ Vulkyn$ sudo gpt -r -vv show disk0


WARNING: Improper use of the sudo command could lead to data loss

or the deletion of important system files. Please double-check your

typing when using sudo. Type "man sudo" for more information.


To proceed, enter your password, or type Ctrl-C to abort.


Password:

gpt show: disk0: mediasize=500107862016; sectorsize=512; blocks=976773168

gpt show: disk0: Suspicious MBR at sector 0

gpt show: disk0: Pri GPT at sector 1

gpt show: disk0: Sec GPT at sector 976773167

start size index contents

0 1 MBR

1 1 Pri GPT header

2 32 Pri GPT table

34 6

40 409600 1 GPT part - C12A7328-F81F-11D2-BA4B-00A0C93EC93B

409640 585937496 2 GPT part - 48465300-0000-11AA-AA11-00306543ECAC

586347136 1269536 3 GPT part - 426F6F74-0000-11AA-AA11-00306543ECAC

587616672 93750880

681367552 295405568 4 GPT part - EBD0A0A2-B9E5-4433-87C0-68B6B72699C7

976773120 15

976773135 32 Sec GPT table

976773167 1 Sec GPT header

Vmini:~ Vulkyn$ sudo fdisk /dev/disk0

Disk: /dev/disk0 geometry: 60801/255/63 [976773168 sectors]

Signature: 0xAA55

Starting Ending

#: id cyl hd sec - cyl hd sec [ start - size]

------------------------------------------------------------------------

1: EE 1023 254 63 - 1023 254 63 [ 1 - 409639] <Unknown ID>

2: AF 1023 254 63 - 1023 254 63 [ 409640 - 585937496] HFS+

3: AB 1023 254 63 - 1023 254 63 [ 586347136 - 1269536] Darwin Boot

4: 0C 1023 254 63 - 1023 254 63 [ 681367552 - 295405568] Win95 FAT32L

Vmini:~ Vulkyn$

Mac mini, OS X Yosemite (10.10.4), Windows 7

Posted on Sep 29, 2015 2:19 AM

Reply
15 replies

Sep 29, 2015 2:35 AM in response to Vulkyn

gdisk output P command


Command (? for help): p

Disk /dev/disk0: 976773168 sectors, 465.8 GiB

Logical sector size: 512 bytes

Disk identifier (GUID): 00007CDE-7F2C-0000-1927-00008C7C0000

Partition table holds up to 128 entries

First usable sector is 34, last usable sector is 976773134

Partitions will be aligned on 8-sector boundaries

Total free space is 93750901 sectors (44.7 GiB)


Number Start (sector) End (sector) Size Code Name

1 40 409639 200.0 MiB EF00 EFI system partition

2 409640 586347135 279.4 GiB AF00 Customer

3 586347136 587616671 619.9 MiB AB00 Recovery HD

4 681367552 976773119 140.9 GiB 0700 BOOTCAMP

Sep 29, 2015 5:59 AM in response to Vulkyn

I will delete partiton 4 bootcamp and rebuild it again 🙂


Oh and thats good news right there 😝 some needs to delete the post on removing mac partition and resizing using partition tools its causing all sorts of problems lol


Also the small clipboard icon is covering the number 😝 not sure how to add that one !

Sep 29, 2015 6:01 AM in response to Loner T

GPT fdisk (gdisk) version 1.0.0


Warning: Devices opened with shared lock will not have their

partition table automatically reloaded!

Partition table scan:

MBR: hybrid

BSD: not present

APM: not present

GPT: present


Found valid GPT with hybrid MBR; using GPT.


Command (? for help): p

Disk /dev/rdisk0: 976773168 sectors, 465.8 GiB

Logical sector size: 512 bytes

Disk identifier (GUID): 00007CDE-7F2C-0000-1927-00008C7C0000

Partition table holds up to 128 entries

First usable sector is 34, last usable sector is 976773134

Partitions will be aligned on 8-sector boundaries

Total free space is 93750901 sectors (44.7 GiB)


Number Start (sector) End (sector) Size Code Name

1 40 409639 200.0 MiB EF00 EFI system partition

2 409640 586347135 279.4 GiB AF00 Customer

3 586347136 587616671 619.9 MiB AB00 Recovery HD

4 681367552 976773119 140.9 GiB 0700 BOOTCAMP


Command (? for help): d

Partition number (1-4):

Sep 29, 2015 7:17 AM in response to Vulkyn

1. Please backup OSX and Windows to separate physical external disks, if possible.

2. Gdisk has a 'b' command, which creates a backup of your GPT and MBR. I suggest a backup and storing externally on a USB or some other media, if there are any future issues.

3. Post a link to the referenced discussion and I will put a clear warning on that thread.

Oh and thats good news right there some needs to delete the post on removing mac partition and resizing using partition tools its causing all sorts of problems lol
