Built-in ethernet vanished

I have the exact same issue after updating to 10.11.3. Can't even add ethernet back in?

I *just* hit this after rebooting.

So apparently the version of the kernel extension for the built-in ethernet driver (AppleBCM5701Ethernet.ext) in OS X 10.11.3 has been added to the blacklist by Apple (AppleKextExcludeList.kext). Specifically versions lower than 10.2.0 have been blacklisted and version 10.1.12 is the one included in OS X 10.11.3.

The blacklist is dynamically pulled by OS X (it's not part of a system update) and I'm not sure what the trigger is exactly. The mod date on the bad AppleKextExcludeList.kext for me was Feb 24. The "good" one is from Nov 12.

I fixed this (probably temporarily) by doing the following:

1. Get the old AppleKextExcludeList.kext from Time Machine Backup and put it somewhere on your hard drive. OS X won't allow you to overwrite it when booted normally.
2. Boot into Recovery mode and overwrite the new /Volumes/<your boot volume>/System/Library/Extensions/AppleKextExcludeList.kext with the old.
3. Purge your kext cache. (kextcache -invalidate /Volumes/<your boot volume>)
4. Reboot back into normal OS X.

If and when OS X pulls the newer AppleKextExcludeList.kext, we'll be back to square one. Hopefully Apple will realize the mistake here soon.

I want to add that the problem manifests itself in a very weird way. The interface says it's "Unplugged" in System Preferences, but you still get a link light on your switch. That's all most people will probably see. If you dig deeper, you notice that ifconfig says en0 doesn't exist and in the Console messages you'll eventually find that the kernel extension is in the exclude blacklist as noted in the second post in this thread. Most people would never find that.

@Matt Kulka: Thank you so much for this. I would have never in 1,000 years figured this out on my own, but it did fix the issue for me. I am eternally grateful!

Now hopefully Apple will fix this so future updates don't repeat this debacle. Thanks again, and take care!

I saved an older version of the AppleKextExcludeList from time machine onto my desktop but I don't understand how to fix the problem in Recovery mode. I've never had to use Recovery Mode and I understand if you can't or don't want to explain to someone unfamiliar with it. Thanks for your time and consideration.

Hi!

Thanks for the solution Matt. I don't have a Time Machine backup neither the ability maybe to repair, so when will Apple solve this? Is there been before this kind of issues? I mean I can connect to the Internet through the wifi, but moving bigger files to a NAS it's going to be quite slow.

Thanks for your time,

Marc

I found some more info: https://www.reddit.com/r/apple/comments/47tfos/warning_software_update_03151913_ breaks_ethernet/

Looks like a secret update, hopefully they will push a new one with the correction soon.

Here's more direct instructions...

1. Download the old exclude list kext from https://www.dropbox.com/s/a9ttv4fy7zl2vtf/AppleKextExcludeList.kext.tgz?dl=0
2. Remember where you put it! Also note the name of your boot volume, the one that defaults to "Macintosh HD".
3. Boot into Recovery mode. Do this by rebooting and holding Command+R until the Apple logo appears.
4. Go to the Utilities dropdown in the menu bar, open Terminal.
5. Do this, replace <boot volume> with your boot volume name from step 2, the quotes are important if there's a space in it (also remember you can list files in your present directory by using ls -a:

   cd "/Volumes/<boot volume>"

   Example: cd "/Volumes/Macintosh HD"
6. Overwrite the newer broken kext with the one you downloaded.

   tar -xvzf "<location of AppleKextExcludeList.kext.tgz>"

   Example: tar -xvzf "Users/matt/Downloads/AppleKextExcludeList.kext.tgz" A couple of things to note here: if you put it in a folder off of your home directory, by default Downloads, you'll need to prepend Users/<username> to it. Notice there's no leading slash, that's because you're working with a location relative to the directory you changed (cd) to earlier. Again, quotes are required if there's a space in any of the path name.
7. Reboot into normal mode (just typing: reboot) and your ethernet should work again.

Final note, while I definitely don't recommend downloading random kexts off the Internet, kexts are now signed and only authentic ones are loaded by default by OS X during a normal boot so the risks are minimal.

Hi Matt,

please check this post, http://forums.macrumors.com/threads/software-update-031-51913-will-break-your-et hernet-driver.1958521/#post-22615494

do you have any idea what should I do with this?

Thanks

Oh neat, somebody found the package for the old kext. Yeah, best bet is to just download that and install it.

http://swcdn.apple.com/content/downloads/60/61/031-44426/436eok9yeg31dav6ro4h1zf y5lkrw3v1oe/AppleKextExcludeList_10_11.pkg

Then just double click it and install it to your boot volume like you would any other installer and reboot.

Hi Matt,

'boot volume' as in 'Macintosh HD' ?

have you tried it yet?

Sorry for all the newbies questions, I am only good at photoshopping 😀

Thanks Matt. Please update us after you try it.

Edit:

oops, someone tried it and still no success

http://forums.macrumors.com/threads/software-update-031-51913-will-break-your-et hernet-driver.1958521/#post-22615556

error message : "This computer does not appear to have any PCI Ethernet cards installed"

First of all, I am terribly disappointed about Apple that things like this happen. It's simply not acceptable! Today suddenly *PLOFF* my ethernet connection on my almost new iMac (Retina 5K, 27-inch, Late 2015) was gone. Checked system preferences > network, nope. No more entry re ethernet. Checked ABOUT THIS MAC and guess what: my Mac has no ethernet card… Ooops! 😮 – Did delete the relevant files in /Library/preferences/SystemConfiguration rebooted, negative. No more ethernet. Reset NVRAM but again to no avail.

While calling Apple Support I booted my iMac in recovery mode and kicked off the OSX El Capitan reinstall. That took 45 mins on my iMac. Exactly the time it took for the Apple Support guy to come to the conclusion that he couldn't help and would have to put me through to his boss to go deeper under the hood. The guy I talked to sent me the link to this thread.

I read it through in parallel on my MacBook and told the Apple guy that I didn't understand how to do this. Maybe this is solution for the super-pros. I would consider myself advanced to pro. I didn't get it and neither could the Apple guy explain how to do what Chris suggests.

But you know what? In the end reinstalling the OS did the job. Ethernet is back and back connected. 🙂 Basically, I successfully helped myself while waiting for Apple support to come up with a solution, 47 minutes in total.

Which brings me back to the beginning of this post: Utterly disappointing! What would my wife do in such a situation with her iMac? What would my 80 year old mother do with her MacBook Air? – Yes, dispair and ultimately turn to me… 😮

Really hope you guys at the Apple engineering department come up with a proper fix for this untenable situation asap.
