El Captain: windows 10 Bootcamp not recognizing after temporary partition

What is the year/model of your Mac? Please post the output of

sudo fdisk /dev/disk0

sudo dd if=/dev/rdisk0s4 count=1 2>/dev/null | hexdump -C

You are on El Capitan.

A. We need to disable SIP.

1. Boot into Local Recovery (Command+R).

2. Start Utilities -> Terminal.

3. Type csrutil disable in Terminal and press Enter/Return.

4. Type csrutil status.

5. Boot normally, and type csrutil status to confirm that all individual entries are still disabled.

B. Mark the NTFS partition bootable. Please ignore the i386 MBR error message, but not any others.

sudo fdisk -e /dev/disk0

p

setpid 4

07

flag 4

p

w

y

Reboot and test.

Excellent. Please back up OS X, Windows, and create a Windows System Restore Point .

Dear Loner T,

I do not know why I couldn't create a new post. So i just post at here.

I have tried the command you given in earlier post, but the window 7 drive didn't show up after i reboot and hold the ALT key.

sudo fdisk -e /dev/disk0
p
setpid 4
07
flag 4
p
write
y

FYI, I am using Macbook Air OS X El Capitan OS X 10.11.3 (15D21).

Hope to hear from you soon. Thank you.

Dear Loner T,

thanks for your help. I have solved the issue. The reason is I didn't boot to recovery mode.

Excellent. Please back up OS X, Windows and create a Windows System restore point.

Dear Loner T,

Do you know how to expand the bootcamp window 7?

I have tried by adjusting the partition in disk utility and it had cause the macbook air failed to boot the wind 7.

Loner T,

I have recently reduced my Macintosh HD by 30GB so that I could increase my bootcamp windows 10 HD by 30GB, but I cannot boot windows after restarting and holding the option key. I've been looking through several forums here, but not sure if my situation is the same, so I'm copying my terminal output here:

AUSTIN-MAC:~ austindailey$ diskutil list

/dev/disk0 (internal, physical):

#: TYPE NAME SIZE IDENTIFIER

0: GUID_partition_scheme *500.1 GB disk0

1: EFI EFI 209.7 MB disk0s1

2: Apple_HFS Macintosh HD 390.3 GB disk0s2

3: Apple_Boot Recovery HD 650.0 MB disk0s3

4: Apple_HFS Untitled 28.9 GB disk0s4

5: Microsoft Basic Data BOOTCAMP 80.0 GB disk0s5

AUSTIN-MAC:~ austindailey$ diskutil mount disk0s3

Volume Recovery HD on disk0s3 mounted

AUSTIN-MAC:~ austindailey$ cat /Volumes/Recovery\ HD/com.apple.recovery.boot/SystemVersion.plist | grep -A 2 ProductVersion

<key>ProductVersion</key>

<string>10.11.2</string>

</dict>

AUSTIN-MAC:~ austindailey$ open /Volumes/Recovery\ HD/com.apple.recovery.boot/BaseSystem.dmg

AUSTIN-MAC:~ austindailey$ cat /Volumes/OS\ X\ Base\ System/System/Library/CoreServices/SystemVersion.plist | grep -A 2 ProductVersion

cat: /Volumes/OS X Base System/System/Library/CoreServices/SystemVersion.plist: No such file or directory

AUSTIN-MAC:~ austindailey$ diskutil list

/dev/disk0 (internal, physical):

#: TYPE NAME SIZE IDENTIFIER

0: GUID_partition_scheme *500.1 GB disk0

1: EFI EFI 209.7 MB disk0s1

2: Apple_HFS Macintosh HD 390.3 GB disk0s2

3: Apple_Boot Recovery HD 650.0 MB disk0s3

4: Apple_HFS Untitled 28.9 GB disk0s4

5: Microsoft Basic Data BOOTCAMP 80.0 GB disk0s5

AUSTIN-MAC:~ austindailey$ diskutil cs list

No CoreStorage logical volume groups found

AUSTIN-MAC:~ austindailey$ sudo gpt -vv -r show /dev/disk0

Password:

gpt show: /dev/disk0: mediasize=500107862016; sectorsize=512; blocks=976773168

gpt show: /dev/disk0: PMBR at sector 0

gpt show: /dev/disk0: Pri GPT at sector 1

gpt show: /dev/disk0: Sec GPT at sector 976773167

start size index contents

0 1 PMBR

1 1 Pri GPT header

2 32 Pri GPT table

34 6

40 409600 1 GPT part - C12A7328-F81F-11D2-BA4B-00A0C93EC93B

409640 762208704 2 GPT part - 48465300-0000-11AA-AA11-00306543ECAC

762618344 1269536 3 GPT part - 426F6F74-0000-11AA-AA11-00306543ECAC

763887880 56375032 4 GPT part - 48465300-0000-11AA-AA11-00306543ECAC

820262912 262144

820525056 156248064 5 GPT part - EBD0A0A2-B9E5-4433-87C0-68B6B72699C7

976773120 15

976773135 32 Sec GPT table

976773167 1 Sec GPT header

AUSTIN-MAC:~ austindailey$ sudo fdisk /dev/disk0

Disk: /dev/disk0 geometry: 60801/255/63 [976773168 sectors]

Signature: 0xAA55

Starting Ending

#: id cyl hd sec - cyl hd sec [ start - size]

------------------------------------------------------------------------

1: EE 1023 254 63 - 1023 254 63 [ 1 - 976773167] <Unknown ID>

2: 00 0 0 0 - 0 0 0 [ 0 - 0] unused

3: 00 0 0 0 - 0 0 0 [ 0 - 0] unused

4: 00 0 0 0 - 0 0 0 [ 0 - 0] unused
