color calibrate on two VDU's after lion upgrade

Question

Level 1

21 points

color calibrate on two VDU's after lion upgrade

Hi,

I have just upgraded my Mac Pro from Snow Lepeord to Lion. All seems to have gone well after the 33min upgrade process completed.

Just noticed that my two identical BenQ HDMI attached monitors are showing different colours (colors) / apprearance. I have tried to change the setting in Display parameters, but although two calibrate windows appear, the right (primary desktop) screen is the only one affected by any changes, even if I try to change the left screen options box.

If I create a new calibration profile, no matter whether I select it on the left or the right screen, you can not independantly select a profile for an individual screen.

Seems to be a problem that has just come with Lion. Has anybody else seen similiar issues, and know a fix or work around?

Just ran the ColorSync application and it reports an error with the dfault BenQ profile

When I Verify:

Checking 60 profiles...

/Library/ColorSync/Profiles/Displays/BenQ V2400Eco-000009D1-0000-7D02-0000-544500000000.icc

Tag 'cprt': Text tag has an incorrect length.

Verify done - found 1 bad profile.

When I Repair:

Searching for profiles...

Checking 60 profiles...

/Library/ColorSync/Profiles/Displays/BenQ V2400Eco-000009D1-0000-7D02-0000-544500000000.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

Repair done - 0 out of 1 profiles fixed.

Dave

Mac Pro 8-Core, Macbook, iPod Touch, iPhone 3GS, iPad 16G, Mac OS X (10.6.4)

Posted on Jul 20, 2011 12:22 PM

Reply

Answer 1

Jul 20, 2011 4:37 PM in response to doozy

Same issue here.

Reply

Answer 2

xgdlm

Level 1

0 points

Jul 21, 2011 9:22 PM in response to doozy

Hello,

Same issue here. I'm not able to select a color profile independantly on each screen. It really seems dual screen support is screwed somehow.

xav

Reply

Answer 3

doozy Author

Level 1

21 points

Jul 22, 2011 7:38 AM in response to xgdlm

Yep, definately something wrong with dual screen setup. I use Screenflow to record desktop activities and it will now only work with the primary vdu. You can select the second screen but it still only records the primary screen.

I think we need a patch !

Dave

Reply

Answer 4

Jul 24, 2011 12:13 AM in response to doozy

Same color profile problem here - can't set new colour profile for my built in MacBook Pro screen. ColorSync ultility reports the same issue you have and is unable to repair. When I try to create a new profile in System Preferences, the new profile cannot be saved.

Definitely a problem that's new with Lion.

Reply

Answer 5

Jul 24, 2011 1:43 PM in response to doozy

I have the exact same issue with my 2 identical Samsung 204T displays on Mac Pro.

Interestingly enough, if I substitute one of the displays with an old Samsung 204bw, everything works as it should - I can assign individual profiles do each display and /library/colorsync/profiles/displays gets 2 different syncmaster entries.

The moment I switch back to two 204T displays, the problem comes back. If I delete all entries in the above mentioned folder, only one Syncmaster entry comes back when booting with two 204T displays.

I looked back at this Mac Pro with Time Machine to see what it did previously under Snow Leopard, when everything worked properly. The above mentioned folder had two Syncmaster entries, one file name ending with 0, the other with 1. The naming scheme was also different from the one in Lion.

So it seems, that unlike Snow Leopard, the Lion can't tell two identical displays apart.

Reply

Answer 6

Jul 25, 2011 12:39 AM in response to michaeltm

So - I read what you said about the fact that Lion treats filenames differently from Snow Leopart and I tried saving my calibration with a very simple title - 'calibration1' - and it worked. That was my problem.

I've now got a recalibrated lapytop screen and recalibrated external screen working just fine. Hope that works for you, too.

Reply

Answer 7

doozy Author

Level 1

21 points

Jul 25, 2011 8:17 AM in response to Giles Colborne

Thanks.

I have tried what you said, and although I can calibrate each display, and save a profile for each with a basic name (Benq1 and Benq2), after the calibration is complete, I can only select one of the two profiles, which is only then applied to display 1, even if I select the profile for dispaly 2 in display 2.

Reply

Answer 8

doozy Author

Level 1

21 points

Jul 25, 2011 8:20 AM in response to michaeltm

Same here. Still no fix.

From ColorSync Utility > Profiles First Aid :

Searching for profiles...

Checking 63 profiles...

/Library/ColorSync/Profiles/Displays/BenQ V2400Eco-000009D1-0000-7D02-0000-544500000000.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

~/Library/ColorSync/Profiles/BenQ1.icc

Tag 'cprt': Text tag has an incorrect length. Fixed.

~/Library/ColorSync/Profiles/BenQ2.icc

Tag 'cprt': Text tag has an incorrect length. Fixed.

Repair done - 2 out of 3 profiles fixed.

But it doesn't repair it

Checking 63 profiles...

/Library/ColorSync/Profiles/Displays/BenQ V2400Eco-000009D1-0000-7D02-0000-544500000000.icc

Tag 'cprt': Text tag has an incorrect length.

~/Library/ColorSync/Profiles/BenQ1.icc

Tag 'cprt': Text tag has an incorrect length.

~/Library/ColorSync/Profiles/BenQ2.icc

Tag 'cprt': Text tag has an incorrect length.

Verify done - found 3 bad profiles.

Reply

Answer 9

xgdlm

Level 1

0 points

Jul 25, 2011 8:45 AM in response to doozy

As michaeltm stated, the problem seems to be with identical displays. In my case I use spyder pro 3 to calibrate my screens, and each time I ended with on screen calibrate and the other one back to the build in profile.

I finnaly managed to have both screen calibrated. How I managed to to it :

I calibrated the first screen. Then the second screen, at the end of the calibration (when everything seems OK) I closed the spyder pro software and the second screens came back to the build in non calibrated profile.

I the screen preferences window, I activated "recopy video" (sorry I don't know exactly how this is translated in an English osx, so both screen displayed the "first" and calibrated screen. Then I deactivated the "recopy video" and then both screen were calibrated using the "first" screen profile. In my case as the displays are identical, it's OK.

I hope Apple is monitoring this thread and will provide a fix with the upcomming update.

Regards,

xav

Reply

Answer 10

Jul 28, 2011 11:50 AM in response to doozy

I had a similar problem, with ColorSync Utility revealing a problem with the iMac-00000610-0000-9..D40.icc file.

ColorSync Utility could not repair it.

Fortunately,I had Snow Leopard backed up on an external drive (I'm using Lion now), so I was able to replace the dodgy file. If anybody has a problem with the same ColorSync Profile file I have mentioned,I will gladly email the file to whoever needs it.

Doug.

Reply

Answer 11

MarioS11

Level 1

0 points

Jul 28, 2011 12:23 PM in response to doozy

I'm having the same problem and ran the ColorSync Utility's repair function and it was unable to fix all three profiles that are broken.

Searching for profiles...

Checking 34 profiles...

/Library/ColorSync/Profiles/Displays/Color LCD-00000610-0000-9CBB-0000-000004272EC0.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

/Library/ColorSync/Profiles/Displays/DELL 2208WFP-000010AC-0000-403B-3632-355300000000.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

/Library/ColorSync/Profiles/Displays/VGA Display-756E6B6E-0000-0717-0000-00005B81C5C1.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

Repair done - 0 out of 3 profiles fixed.

Reply

Answer 12

Jul 29, 2011 5:21 AM in response to MarioS11

I got the same problem.

still no solution?

thanks

Reply

Answer 13

pug1334

Level 1

24 points

Jul 30, 2011 8:19 PM in response to thomas21de

Same here. I believe it's going to take a lot of software updates for Lion.

Reply

Answer 14

Aug 2, 2011 7:16 AM in response to Wizard_Magic_Spell

Doug, I have I Samsung SyncMaster 940BW that has been working fine on Lion until I moved the system. Now I Have four files that are non-repairable in the Color Sync Utility. I wish your file would repair my issue.

/Library/ColorSync/Profiles/Displays/Display-00004C2D-0000-0226-4841-31390000000 0.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

/Library/ColorSync/Profiles/Displays/Display-756E6B6E-7669-7274-0000-000041DC9D0 1.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

/Library/ColorSync/Profiles/Displays/SyncMaster-00004C2D-0000-0226-4841-31390000 0000.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

/Library/ColorSync/Profiles/Displays/SyncMaster Calibrated.icc

Tag 'cprt': Text tag has an incorrect length.

The file is locked. Could not be fixed.

I have performed Disk Repair Permissions Numerous Times.

Chris

Reply

Answer 15

Aug 2, 2011 8:16 AM in response to christopher62

Hi Chris,

I have checked Snow Leopard on my external drive for you and,sorry,but the only Displays info on it is for my iMac.

I presume you don't have an external drive with Snow Leopard backed up ? But if you do have a back-up, the solution would be to drag the Displays file into Lion.

Reply
