Windows Boot Manager error, winload.exe

Hello,


MacPro 3,1

Windows 7 & 10.9.5


Mac OS and Windows partition on same disk


I've been reading threads here on the apple board and elsewhere on the net. Tried the easier fixes with no luck. (No USB devices on boot, zapping Pram, CommandS fsck operations, etc)


I've had no hardware or mac os updates in a very long time. Bootcamp was working fine for years, then suddenly not working.

I'm wondering if I do have some corruption going on..


My Windows 7 (64), is a Vista upgrade


DiskUtil list



Diskutil cs list


sudo gpt -vv -r show /dev/disk0


sudo fdisk /dev/disk0


Many thanks for any help!

Andre

Posted on Jun 25, 2021 8:15 PM

Reply
Question marked as Top-ranking reply
User profile for user: Loner T
Loner T
User level: Level 9
59,536 points

Posted on Jun 28, 2021 6:11 PM

The command we used does not repair the GPT. To repair it, we need to run GPT FDisk in interactive menu. See https://www.rodsbooks.com/gdisk/gdisk.html for reference. A reboot can re-order disks, so be careful.


You need to run (do not type text like this). Let us try to repair disk0 (your macOS disk). Be careful, in each menu, the one-character command can mean different types of requests.


sudo gdisk /dev/disk0

2 (Choose 2, if prompted)

p (print)

x (Experts menu)

n (New Protective MBR)

o (print Protective MBR)

p (print GPT)

w (write the updated GPT)

y (confirm write)

q (quit, if necessary)


Do not reboot. Now post the output of


diskutil list


before we go further.

View in context

Similar questions

60 replies
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 26, 2021 12:26 PM in response to Loner T

Hey LonerT


Do you think the fact that I'm using a PCIe SSD OWC excelsior card as the main boot drive (1TB into 2 partitions, Windows7/OSX)

using the Apricorn Velocity Solo X2 BIOS


Might have something to do with my issues?


I made a USB bootable drive with NeoSmart's Easy Recovery Essential, but the USB drive is not recognized when holding down the option key on boot


I also made a bootable CDRom disk with Easy Recovery, yet I think my CDRom drive is not working/dead...


Any thoughts?

Reply
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 27, 2021 8:16 AM in response to Loner T

Ok, I will try that and reply back...

I took apart the DVD Rom drive, greased up the rails, cleaned out the dust, etc...

it's working and powers up fine... but there seems to be something going on, where I cannot get it to recognize any disks (Mac OSX) or boot from any boot able CD/DVD (option key)


I pulled all the drives out

I swapped video cards


It seems I have to figure out how to get the DVD drive to function properly, before I can get to the necessary next steps.


(On another note, I just used Windows 10 SandBox feature to do the task/work I needed to get done with BootCamp. )

Reply
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 27, 2021 1:46 PM in response to Loner T

I replaced the IDE DVD drive, booted off the recommended NeoSmart recovery tool

Read their website, no mention of compatibility with bootcamp...


gave it a start, it booted

ran the easy repair

it completed


Seems like it tampered with my main Mac OSX drive

My Mac OSX drive is now wiped with a EFI designation , booted into TechTool edisk, see that the drive has no files... TechTool doesn't offer any recovery tools on that drive


I guess I can see if I can boot with a Mac OSX disk, see if there's any recovery tools

looks like I lost all the data on the Apricorn drive (main mac osx)


Ugh


Reply
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 27, 2021 5:06 PM in response to Loner T

Currently I'm running off a TechTool Pro eDisk (emergency partition)


I'm going to install GPT fdisk on a windows 10 recovery USB bootable

I'll give that a shot


Although I just mounted the USB drive (within the techtool pro environment)

I see it mounted to the desktop


Do you think I can run the GPT fdisk off that USB drive , from within the techtool environment (I can launch Terminal) it appears from the GPT fdisk sourceforge site, it can run in Linux, Mac, Windows... so I think I can probably run it in Terminal (from the TechTool eDisk)



Reply
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 28, 2021 10:07 AM in response to Loner T

Yes I've installed it on the USB disk, I've been trying to read up on the program.

Do you know what commands in Terminal I should be typing to get it to possibly fix the drives?


many thanks for your help on this


Also, since I purchased NeoSmart software and now have that, is there any tools within that program that might undo what it has done?


thanks

Reply
User profile for user: Loner T
Loner T
User level: Level 9
59,536 points

Jun 28, 2021 3:38 PM in response to dreko71

When you download GPT Fdisk from macOS you will get a binary, which is


file /usr/local/bin/gdisk
/usr/local/bin/gdisk: Mach-O 64-bit executable x86_64


If you do the same on a Windows PC (or Bootcamp MAC), you will get an executable which is


gdisk64.exe 0:
GPT fdisk (gdisk) version 1.0.8

Partition table scan:
  MBR: protective
  BSD: not present
  APM: not present
  GPT: present

Found valid GPT with protective MBR; using GPT.

Command (? for help): p
Disk 0:: 488552530 sectors, 1.8 TiB
Sector size (logical): 4096 bytes
Disk identifier (GUID): 95315930-1791-4E79-9813-E7A9050E157C
Partition table holds up to 128 entries
Main partition table begins at sector 2 and ends at sector 5
First usable sector is 6, last usable sector is 488552524
Partitions will be aligned on 2-sector boundaries
Total free space is 559 sectors (2.2 MiB)

Number  Start (sector)    End (sector)  Size       Code  Name
   1               6           76805   300.0 MiB   EF00  EFI System Partition
   2           76806       245438207   936.0 GiB   AF0A
   3       245438208       488417565   926.9 GiB   0700
   4       488417792       488552191   525.0 MiB   2700

Command (? for help):


Reply
User profile for user: dreko71
dreko71 Author
User level: Level 1
9 points

Jun 29, 2021 10:53 AM in response to Loner T

Ok, I cannot boot into boot camp drive


When holding the option key during startup, there's no longer a Bootcamp drive/OS


However, when I boot back into Mac OSx, it mounts right on the desktop and I see all the files/directories.


I did run the following steps on the bootcamp drive:

sudo gdisk /dev/disk1

2 (Choose 2, if prompted)

p (print)

x (Experts menu)

n (New Protective MBR)

o (print Protective MBR)

p (print GPT)

w (write the updated GPT)

y (confirm write)

q (quit, if necessary)


I think I just realized, I haven't used it on disk2

I think that is the bootcamp drive, yes?


Reply
